Catalog #
Q.TRON BLK M-G2.H1+/AC 430
Mfr. Part #
Q.TRON BLK M-G2.H1+/AC 430
Manufacturer
Category
Unit Price
For wholesale pricing and availability contact your local Greentech Renewables or:
Technical Specifications
Watts PTC
325
Watts STC
430 W
Cells
108
Technology
N-Type TOPCon
Open Circuit Voltage (Voc)
39.32
Short Circuit Current (Isc)
13.74
Max Power Voltage (Vmpp)
32.94
Max Power Current (Impp)
13.05
Max Current
25 A
Efficiency
22.0
Frame Material
Anodized Aluminum
Frame Thickness (mm)
40
Frame Color
Black
Backsheet Material
Composite Film
Connector
Staubli MC4
Output Cables
4mm2 Solar cable
Temp Coefficient (Pmpp)
-0.30
Temp Coefficient (Voc)
-0.24
Fire Classification (Type)
Type 2
General Information
Dimensions
1722 L x 1134 W x 40 H mm
Weight
50.59
Series
Q.Tron AC
Approvals
UL 61730-1 & UL 61730-2
CE-compliant
Quality Controlled PV -TUV Rheinland
IEC 61215:2016
IEC 61730:2016
